Provide high-precision static and dynamic measurements of well inclination, tool face, temperature, real-time rotation state of the drill string, and sensor position.
Automatically allocates the gamma ray signal to 8 sectors based on the rotation state of the drill, offering high-precision 8-sector measurement (customizable features).
The internal circuit unit provides real-time dynamic high-precision positional information for other logging-while-drilling instruments, complementing parameter measurements for imaging functions.
Applicable for logging-while-drilling azimuthal gamma, multi-sector gamma measurement, and gamma imaging.
Product Details
Product Specifications
| Gamma measurement | 8-curve data |
| Measurement range | 0-500API, ±2API@100API |
| Operational speed | 0-300RPM, ±1RMP |
| Temperature measurement | -40°C~150°C, ±0.3°C |
| Well inclination | 0-180° (static inclination ±0.1°; dynamic inclination ±0.2°) |
| Tool face | 0-360° |
| Fault-free operating time | ≥1000 hours |
| Speed signal output mode | OC gate |
| Vibration, shock | MWD standard |
